Elastomeric (Rubber) Expansion Joints

Garlock Style 204 Expansion Joint

Styles 204 and 204HP spool-type expansion joints can be constructed as single- or multiple-arch types. They connect pipe flanges in concentric or eccentric tapers, to join piping of unequal diameters.

Style 204 Spec Sheet

Garlock Style 206 EZ-FLO

EZ-FLO expansion joints contain a single wide flowing arch, eliminating the need for filled arches on slurry services. Garlock EZ-FLO expansion joints have successfully served all major industries, including pulp and paper, steel, waste and water, HVAC, power generation, chemical, petrochemical and marine.

Style 206 EZ-FLO Spec Sheet

Kenneth Industrial supplies numerous expansion joints in accordance with U.S. Navy specifications.

Style 9278 EZ-FLO is designed to meet the requirements of ASTM F1123, and is constructed of neoprene and polyamide. Retaining rings must be galvanized in accordance with the specification.

Style 7706 S-type (as pictured) has been developed specifically for submarine service. Other styles are available per application.

Kenneth Industrial supplies expansion joints certified to Coast Guard Specification 46CFR56.60-25(E).
